The VC810 is an HDMI-to-VGA converter that allows you to connect an HDMI source (e.g. laptop, PC, ultrabook, etc) directly to a VGA display (e.g. projector, LCD monitor, etc) without
Features
- Converts HDMI signals to VGA output
- Superior video quality – up to 1920 x 1200, 1080p
- Supports wide screen formats
- Non-powered
Video Input
- Interfaces
- 1 x HDMI Type A Male (Black)
- Impedance
- 100 Ω
Video Output
- Interfaces
- 1 x HDB-15 Female (Black)
- Impedance
- 75 Ω
Video
- Max. Pixel Clock
- 200 MHz
- Max. Resolution
- Up to 1920 x 1080/60Hz
Environmental
- Operating Temperature
- 0 - 60 ºC
- Storage Temperature
- -10 - 70 ºC
- Humidity
- 40 - 85% RH, Non-Condensing
Physical Properties
- Housing
- Plastic
- Weight
- 0.01 kg ( 0.02 lb )
- Dimensions (L x W x H)
- 4.55 x 2.30 x 1.48 cm (1.79 x 0.91 x 0.58 in.)
- Carton Lot
- 40 pcs
- Note
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
