Повторител за VGA сигнал по Cat 5e, съвместим с ATEN KVM и видео удължители; удвоява обхвата на предаване до 300 m, а с допълнителен повторител разстоянието се увеличава още.
Характеристики
- VGA signal extension over Cat 5e Cable
- Extends the video transmission range up to twice the original distance
- Expandable Range-using an additional repeater to increase distance transmission
- Adjustable Gain Control-manually adjusts signal strength to compensate for distance
- Built-in 8KV ESD protection and 2KV surge protection
- LED display for easy status monitoring
- Compact Size-Din Rail and Wall mountable
- Compatible with ATEN Extenders: CE250A, CE252, CE700A, VE150A
Видео
- Макс. разстояние
- 300 m
Конектори
- Захранване
- 1 x DC Jack
- Консумация
- DC5.3V:1.85W:9BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Работна среда
- Работна температура
- 0 - 50°C
- Температура на съхранение
- -20 - 60°C
- Влажност
- 0 - 80% RH, Non-Condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- 0.14 kg ( 0.31 lb )
- Размери (Д x Ш x В)
- 7.90 x 7.16 x 2.44 cm (3.11 x 2.82 x 0.96 in.)
- Брой в кашон
- 5 pcs
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
