Адаптер от DisplayPort към VGA за монитори и проектори с HDB-15 вход, с изход до 1920x1200. Работи без инсталация на софтуер или драйвери.
Характеристики
- Converts DisplayPort signals to VGA output
- DisplayPort 1.2 compliant
- Supports VGA, SVGA, XGA, SXGA, UXGA and resolutions up to 1920x1200 (PC) / 1080p (HDTV)
- No software or driver installation required
Видео вход
- Интерфейси
- 1 x DisplayPort Male (White)
Видео изход
- Интерфейси
- 1 x HDB-15 Female (Blue)
Видео
- Макс. пикселна честота
- 165 MHz
- Макс. резолюция
- Input up to 4096 x 2160@60Hz (4:4:4) Output up to 1920 x 1200
- Съответствие
- DP1.2
Работна среда
- Работна температура
- 0 - 50 ºC
- Температура на съхранение
- -20 - 60 ºC
- Влажност
- 0 - 80% RH, Non-Condensing
Физически характеристики
- Корпус
- Plastic
- Тегло
- 0.04 kg ( 0.1 lb )
- Размери (Д x Ш x В)
- 18.00 x 4.50 x 1.50 cm (7.09 x 1.77 x 0.59 in.)
- Брой в кашон
- 40 pcs
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
