16-Port Serial Console Server
SN9116Снет от производство
Конзолен сървър за отдалечен достъп до 16 серийни устройства през RJ-45 портове. Осигурява защитен in-band и out-of-band достъп до серийните конзоли на оборудването през браузър с графичен интерфейс.
Характеристики
- System Accessibility and Availability
- Secure in-band and out-of-band remote serial console access
- In-band Ethernet access of serial devices
- Browser access with an intuitive GUI
- Terminal-based access with a menu-driven UI
- Out-of-band access via dial-up modem
- Modem dial-in/dial-back/dial-out
- Serial Console Management
- Convenient and simple serial device access via browser or Telnet/SSH client
- Port access via Telnet/SSH client and third-party clients such as PuTTY
- Direct port access from Telnet client – bypasses SN login
- Convenient port access via the applet serial viewer from SN Web GUI
- Selectable Telnet or SSH serial viewer
- Selectable ActiveX or Java serial viewer
- Comprehensive viewer function – Copy/paste, logging, data import, Macro, broadcast and Message Board
- Sun Solaris ready – Sun “break-safe”
- Alert Strings
- Command filter – administrators can define what commands cannot be executed by users
- Data buffering
- Multiple users can simultaneously access to the same port – up to16 connections per port
- Selectable mode for multiple simultaneous access – Exclusive/Occupy/Share mode
- Integrated with Power Over the NET™ product for port and power outlet association
- Security
- SSH and SSL (TLS v1.0 / TLS v1.1 / TLS v1.2) support
- Secure login from browser with TLS 1.2 data encryption and RSA 2048-bit certificates
- Configurable user permissions for port access
- Configurable group permission for port access
- Local and remote authentication and logging
- Third-party authentication via RADIUS, TACACS+, LDAP/AD and Kerberos
- IP filtering and MAC filtering
- System Management
- System configuration via web browser, Telnet/SSH client and local console
- System log and event logging
- Comprehensive logging and event notification
- ATEN Log server and Syslog server
- SNMP agent
- Event notification – via SMTP email, SNMP Trap and SMS (to mobile devices)
- Backup/restore system configuration
- Firmware upgradeable
- Multi-browser support – Internet Explorer, Chrome, Firefox, Safari, Opera and Mozilla
- Customizable global time zone
- NTP for time server synchronization
- DHCP for dynamic IP address assignment
- IPv6 support
- Integrates with CC2000 for centralized data center management
- Serial Device Management
- Versatile serial operating modes – support Real COM, TCP Server, TCP Client, UDP, Serial Tunnel and Virtual Modem
- 128-bit/256-bit SSL encryption (TLS v1.0 / TLS v1.1 / TLS v1.2) for Real COM, TCP Server, TCP Client, Serial Tunnel and Virtual Modem
- Real COM driver for Windows 2000 or higher and Windows Server 2003/2008
- Real TTY driver for Linux
- Fixed TTY driver for UNIX
- Language
- Web-based GUI multi-language – available for English, German, Japanese, Korean, Russian, Simplified Chinese and Traditional Chinese
Спецификация
- Връзки
- 16
Конектори
- Сериен
- 16 x RJ-45 Female
- LAN портове
- 1 x RJ-45 Female
- Захранване
- 1 x IEC60320/C14
Бутони и превключватели
- Нулиране
- 1 x Recessed Pushbutton
- Захранване
- 1 x Rocker Switch
Индикатори
- Сериен
- 16 (Green)
- 10/100/1000 Mbps
- 1 (Red / Orange / Green)
- Захранване
- 1 (Blue)
- Макс. входна мощност
- 100-240V~, 1A, 50/60Hz
- Консумация
- AC110V:10.9W:51BTU/h AC220V:11.6W:54BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Работна среда
- Работна температура
- 0 - 40˚C
- Температура на съхранение
- -20 - 60˚C
- Влажност
- 0 - 80% RH, Non-condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- 3.16 kg ( 6.96 lb )
- Размери (Д x Ш x В)
- 43.72 x 21.76 x 4.40 cm (17.21 x 8.57 x 1.73 in.)
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
