32-Port Serial Console Server with Dual Power / SFP
SN1132CO
Конзолен сървър за защитен отдалечен достъп in-band и out-of-band до 32 серийни RJ-45 порта и USB конзоли. Двойно захранване и 2 x SFP слота за резервираност; управление през браузър, терминал или модем.
Характеристики
- Secure in-band, out-of-band remote serial console and USB console access
- Browser access with an intuitive GUI
- Terminal-based access with a menu-driven UI or command-line interface
- Modem dial-in / dial-back / dial-out access
- Front USB ports for storage, USB console1, and UC232B/UC232BF connection
- Laptop USB Console (LUC) port for local console access via laptop
- Dual Ethernet ports allow fail control or dual IP address access
- Dual power supply
- USB 4G dongle support – enables cellular out-of-band redundancy2
- Support sensor ports for environmental monitoring3
- Relay port supports cabinet door access control
- Auto-sensing DTE / DCE feature supports a direct connection to Cisco network switches (and other compatible devices) without rollover cables for more convenient IT infrastructure deployment
- Online / Offline detection of connected serial devices (including terminal blocks) – automatically send event notifications when the devices are offline (e.g. power failure) for device status monitoring
- Response Check – checks the system status of the connected serial devices, and sents a notification if the check fails (e.g.system crash)
- Convenient and simple serial device access via selectable Telnet / SSH and third-party clients such as PuTTY
- Easy port access via selectable ActiveX, Java serial viewer or WebClient
- Comprehensive viewer functions – copy / paste, logging, data import, macros, broadcasting and message board
- Sun Solaris ready – Sun "break-safe"
- Alert Strings – whenever one of the pre-defined strings matches the message sent from the serial devices, you will be informed by serial console server via SNMP Trap alert and / or an email
- Command filter – administrators can restrict users to execute only pre-defined commands
- Multiple users can simultaneously access the same port – up to 16 connections per port
- Modes for simultaneous access – Exclusive / Occupy / Share mode
- Supports secure login from browsers with TLS 1.2 data encryption and RSA 2048-bit certificates
- Configurable user permissions for port access and control
- Local and remote authentication and login
- Third-party authentication via RADIUS, TACACS+, LDAP / AD and Kerberos
- IP and MAC address filter for enhanced security protection
- High security grade – supports FIPS 140-2 level 1 security standards that use an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate #1747, #2398, #2473)
- Supports security level configuration – High, Medium-high, Medium or Custom, to ensure a fine granularity of network access control
- IEEE 802.1X compliant
- Supports SSH password-less login for enhanced security and simplified access management
- System configuration via web browser, Telnet / SSH client and local console
- System log and event login
- Event Destination – Event logs will be saved to Log server, Syslog server, and USB drive3
- SNMP agent v1/v2c/v3
- Event notification – supports notification of SMTP email and SNMP Trap (v1/v2c/v3)
- Backup / Restore system configuration and upgradeable firmware
- Multi-browser support – Internet Explorer, Chrome, Firefox
- NTP for time server synchronization
- IPv4 / IPv6 support
- LLDP support
- CLI (command-line interface) support
- Integrates into CC2000 software for centralized data center management
- Integrates into CCVSR software for user session recording
- Serial operation modes – Console Management, Console Management Direct, Real COM Port, TCP Server / Client, UDP Server / Client, and Virtual Modem
- Real COM driver for Windows 2000 or higher and Windows Server 2003 / 2008
- Real TTY driver for Linux
- Fixed TTY driver for UNIX4
- Supports baud rates of 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 28800, 38400, 57600, 115200, 230400 bps
- Multi-language web-based GUI – available in English, German, Japanese, Korean, Russian, Simplified Chinese and Traditional Chinese Note: 1. Compatible models: Cisco Catalyst 2960-C series 2. Supports the ZTE MF79U only. 3. This is achieved using ATEN sensors 4. Fixed TTY Driver supports: OpenServer (Sco Unix), UnixWare 7, SVR 5, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, FreeBSD, Solaris 10, AIX 5.x, HP-UX 11i
Конектори
- Сериен
- 32 x RJ-45 Female
- LAN портове
- 2 x SFP Slot
- Захранване
- 2 x IEC 60320/C14
- Локална конзола
- 1 x RJ-45 Female
- PON
- 1 x RJ-45 Female (Reserved)
- Laptop USB Console (LUC) порт
- 1 x Mini USB
- USB порт
- 4 x USB Type A Female
- Портове за сензори
- 2 x RJ11 Female 1 x 4-Pin Terminal Block
- Реле
- 1 x 2-Pin Terminal Block • Normally open, isolated Relays; • Contact Rating: Max 24 VDC, 2A
Бутони и превключватели
- Захранване
- 2 x Rocker Switch
- Нулиране
- 1 x Recessed Pushbutton
- Макс. входна мощност
- 100–240VAC; 50/60Hz; 1.0A
- Консумация
- AC110V:11.2W:105BTU/h AC220V:11.3W:105BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Индикатори
- Сериен
- 32 (Green)
- 10/100/1000 Mbps
- 2 (Red/Orange/Green)
- Захранване
- 2 (Blue)
- Режим на работа
- Console Management, Console Management Direct, Real Com Port, TCP Server/Client, UDP Server/Client
Работна среда
- Работна температура
- 0 - 55˚C
- Температура на съхранение
- -20 ~ 60˚C
- Влажност
- 0 - 80% RH, Non-condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- 4.60 kg ( 10.13 lb )
- Размери (Д x Ш x В)
- 43.84 x 32.84 x 4.40 cm (17.26 x 12.93 x 1.73 in.)
- Забележка
- - SN1132COD with dual DC power available at customer’s request - Optional fiber (2A-136G, 2A-137G) or copper (2A-143G) modules available - Optional sensors (EA1140, EA1240, EA1340, EA1440, EA1441, EA1442, EA1540) available
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
