USB HDMI Dual View HDBaseT™ 2.0 KVM Extender (4K@100m for Single View)
CE824
HDBaseT 2.0 KVM удължител с два HDMI изхода (Dual View): пренася видео, аудио, USB и RS-232 по един Cat 6/6a кабел, до 4K на 100 m при единичен дисплей; 4 USB порта за периферия.
Характеристики
- Allows HDMI dual view access to a distant computer for KVM control from remote console
- Transmits uncompressed HDMI video / stereo audio / USB / RS-232 signals via one single Cat 6 / 6A / ATEN 2L-29330 cable over long distances: – Standard mode supports single view at up to 4K or dual-view up to 1080p over 100 m – Long Reach mode supports single view at up to 1080p or dual-view up to 720p over 150 m*
- 4 x USB 2.0 Type-A ports on the remote unit for connection to multiple USB peripherals
- Supports 2-channel stereo audio
- EDID buffer for smooth power-up and the highest quality display
- PC wakeup function enabled via a pushbutton through RS-232
- HDCP compatible
- Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
- DC Jack with screw-lock ensures stable and secure connection
- Rack mountable Note: 1080p @ 150 m can only be achieved via single display installation.
Конектори
- KVM портове
- 2 xHDMI Female (Black) 1 x USB Type B Female (White) 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Pink)
- KVM портове
- N/A
- Конзолни портове
- N/A
- Конзолни портове
- 2 x HDMI Female (Black) 4 x USB Type A Female (White) 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Pink)
- RS-232
- 1 x DB-9 Female (Black)
- RS-232
- 1 x DB-9 Male (Black)
- Захранване
- 1 x DC Jack (Black)
- Захранване
- 1 x DC Jack (Black)
- Между устройства
- 1 x RJ-45 Female (Black)
- Между устройства
- 1 x RJ-45 Female (Black)
Индикатори
- Захранване
- 1 (Green)
- Захранване
- 1 (Green)
- Връзка
- 1 (Orange)
- Връзка
- 1 (Orange)
- Видео изход
- N/A
- Видео изход
- 2 (Orange)
Бутони и превключватели
- Превключвател Long Reach
- 1 x Slide Switch
- Превключвател Long Reach
- 1 x Slide Switch
- Обновяване на фърмуера
- 1 x Slide Switch
- Обновяване на фърмуера
- 1 x Slide Switch
Бутони
- Бутон за събуждане
- N/A
- Бутон за събуждане
- 1 x Pushbutton
- Видео
- Single view: Up to 4K@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A) 1080P@150m (Cat 6/6a/ATEN 2L-29330 Cat 6A) with Long Reach Mode enabled Dual-view: Up to 1080p@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A) *4K supported: 4096 x 2160 @ 60Hz (4:2:0), 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
- Видео
- Single view: Up to 4K@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A) 1080P@150m (Cat 6/6a/ATEN 2L-29330 Cat 6A with Long Reach Mode enabled Dual-view: Up to 1080p@100m (Cat 6/6a/ATEN 2L-29330 Cat 6A) *4K supported: 4096 x 2160 @ 60Hz (4:2:0), 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
- Консумация
- DC12V:5.98W:28BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
- Консумация
- DC12V:10.32W:57BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Работна среда
- Работна температура
- 0–40°C
- Работна температура
- 0–40°C
- Температура на съхранение
- -20–60°C
- Температура на съхранение
- -20–60°C
- Влажност
- 0–80% RH, Non-condensing
- Влажност
- 0–80% RH, Non-condensing
Физически характеристики
- Корпус
- Metal
- Корпус
- Metal
- Тегло
- 0.79 kg ( 1.74 lb )
- Тегло
- 0.82 kg ( 1.81 lb )
- Размери (Д x Ш x В)
- 17.42 x 15.59 x 2.88 cm (6.86 x 6.14 x 1.13 in.)
- Размери (Д x Ш x В)
- 17.42 x 15.59 x 2.88 cm (6.86 x 6.14 x 1.13 in.)
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
- Отдалечен HDMI изход
- 640 x 480 @ 60/67/72/75 Hz
- Отдалечен HDMI изход
- 1920 x 1200 @ 60 Hz (+ Reduced Blanking)
- 720 x 400 @ 70 Hz
- 1080p @ 24/25/30/50/60 Hz
- 800 x 600 @ 56/60/72/75 Hz
- 480p @ 60 Hz (4:3 / 16:9)
- 1024 x 768 @ 60/70/75 Hz
- 720p @ 50/60 Hz
- 1280 x 800 @ 60 Hz
- 1080i @ 50/60 Hz
- 1280 x 1024 @ 60/75 Hz
- 576p @ 50 Hz (4:3 / 16:9)
- 1400 x 1050 @ 60 Hz
- 3840 x 2160p @ 24/25/30 Hz
- 1440 x 900 @ 60 Hz
- 3840 x 2160p @ 50/60 Hz 4:2:0
- 1600 x 1200 @ 60 Hz
- 4096 x 2160p @ 24/25/30 Hz
- 1680 x 1050 @ 60 Hz
- 4096 x 2160p @ 50/60 Hz 4:2:0
- 1920 x 1080 @ 60 Hz
