8-Port PS/2 VGA KVM Switch with Daisy-Chain Port
ACS1208AСнет от производство
KVM превключвател в 1U — една PS/2 конзола управлява 8 компютъра, а чрез daisy-chain на още 31 устройства до 256. Обновяване на фърмуера на цялата верига едновременно.
Характеристики
- One PS/2 console controls 8 computers.
- Daisy chain up to 31 additional units - Control up to 256 computers from a single console.
- Firmware upgrades to all the chained KVM switches at the same time via the daisy chain cable.
- Buzzer ON/OFF via hotkey and OSD.
- Broadcast Mode: Operations simultaneously performed on all selected computers, software installation and upgrading, system wide shutdown....etc.
- Auto-sensing of station's position on daisy chained installations - no need for manual DIP switch setting - front panel LED indicates station's position.
- Computer selection via hotkeys and OSD.
- Superior video quality- up to 2048 x 1536; DDC2B.
- Rack mountable in 19" system rack.
- Multiplatform support: Windows 2000/XP/Vista, Linux and FreeBSD.
- For more information about KVMs which can connect to ACS1208A, see Compatible KVM Table.
Връзки към компютри
- Директно
- 8
- Максимум
- 256 (via Daisy-chain)
- Избор на порт
- OSD, Hotkey
Конектори
- Конзолни портове
- 1 x 6-pin Mini-DIN Female (Purple) 1 x HDB-15 Female (Blue) 1 x Mini Din 6 Female (Green)
- KVM портове
- 8 x SPHD-15 Female (Yellow)
- Daisy Chain портове
- 1 x DB-25 Female (Black) 1 x DB-25 Male (Black)
- Обновяване на фърмуера
- 1 x RJ-11 Female (Black)
- Захранване
- 1 x DC Jack (Black)
Бутони и превключватели
- Обновяване на фърмуера
- 1 x Slide
- Нулиране
- 1 x Semi-recessed Pushbutoon
Индикатори
- Онлайн
- 8 (Orange)
- Избран
- 8 (Green)
- ID на станция
- 2 x 7-segement (Orange)
- Захранване
- 1 (Blue)
Емулация
- Клавиатура / мишка
- PS/2
- Видео резолюция
- 2048x1536;DDC2B
- Интервал на сканиране
- 1-255 Seconds
- Консумация
- DC9V, 7.5W Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Работна среда
- Работна температура
- 0-50˚C
- Температура на съхранение
- -20-60˚C
- Влажност
- 0-80% RH, Non-condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- kg ( 0 lb )
- Размери (Д x Ш x В)
- x x cm (0 x 0 x 0 in.)
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
